Contactless safety switches do not require a conductive, mechanical connection to break or make a circuit. They are well-suited for applications where the precise placement of safety switches is difficult, and higher tolerances are required.
Due to the lack of mechanical, moving parts, they require low maintenance, and are resistent to vibration and shock. By desing, they are generally made of two parts, a sensor and an actuator. The sensing distance is 7-12mm (depending on exact model).
Comitronic BTI offers a wide range of contactless safety switches, including coded contactless safety switches, RFID uniquely coded switches, EX solution for zone 0 - zone 20 and contactless interlocking solutions.
AMX series | DATASHEET |
autonomous, self-checking | |
max. load | 2A/48V |
performance class | PLc (autonomous) or PLe (external AWAX controllerrel) |
housing | PA6 or 316L |
protection | IP68 or IP69K |
connection | 3, 6, 12 m cable, or 50 cm M12 8 pin connector |
SSR series | DATASHEET |
autonomous | |
max. load | 2A/250V |
performance class | PLc (autonomous) or PLe (with AWAX controller) |
housing | PA6 or 316L |
connection | 3, 6, 12 m kábel, or 50 cm M12 8 pin connector |
protection | IP68 or IP69K |
OPTO2S mniature safety switch | DATASHEET |
autonomous | |
miniature | |
max. load | 250mA/48V |
performance class | PLc (autonomous) or PLe (with AWAX controller) |
housing | PA6 |
protection | IP68 |
connection | 3, 6, 12m cable |
